DESCRIPTION

Basic Info.

Model NO.	CDH-600U
Drilling Way	Rotary
Transport Package	Nude Packing
Specification	3, 700x1, 790x2, 160mm
Trademark	Bohwa
Origin	China
HS Code	84304900

Product Description

Drilling Capacity
Drill Rod Downward Hole (m)
HQ 150

Power Unit
Electromotor model BM2-250M-4-B35
Power 55Kw
Electromotor RPM 1,480rpm
Rotator
Max. Torque 1,030Nm
Max. Rotation speed 1,145rpm
Feeding stroke 1,800mm
Max. Spindle dia. 97mm
Max. Pulling force 65Kn
Max. Feeding force 65Kn
Hydraulic System
Pressure 26MPa
Cooling Water cooled
Drill Mast
Length 3.3-5.8m
Drilling angle -90 degree~+90degree;
Dump length 1.1m
Hydraulic Rod Holder
Drill rod AKU, BKU, NKU, HKU
Transportation Dimensions
Main frame 3,700x1,790x2,160mm
Power unit 2,980x1,210x1,560mm
Control table 785x680x950mm

Besides drilling rig, we can also supply drilling instruments and auxiliary equipment.Our products including but not limited to:1. Drill rod/Casing Pipe2. Inner Tube/Outer Tube3. Split Tube4. Surface set /Impregnated diamond Core Bits5. Surface set /Impregnated diamond Reaming Shell5. PDC bits6. Casing(Rod) shoes/Casing bits7. Core Barrel Assembly(Core lifter, Core Lifter Case, Locking Coupling, Adapter Coupling, Landing Ring, Inner Tube Stabilizer and etc)8. Head Assembly/OvershotAssembly9. Core lifter, core lifter case7. Diamond circle wrench8. Wrench for Drill Rod/InnerTube/Outer Tube9. Water Swivel/ Hoisting Plug10. Recovery Tap and Adapter Subs11. Plastic Core Box(Core Tray)We can supply full set of drilling instruments and drilling tools to meet your different drilling requirements. Please contact us for detailed information.
