Overview

Basic Info.

Model NO.	DL430J
Certification	ISO 9001:2000, ISO 9001:2008
Condition	New
Drill Hole Diameter	<100mm
Drill Hole Depth	>150m
Bit Type	Cone Bit
Drilling Way	Rotary
Type	Crawler
Max Moving Speed of Power Head	50 M/Min
Configuration	Poclian Motor 194kw Engine
Performance	Push Pull Speed Faster Than
Size	7550mm*2300mm*2520mm
Weight	13t
Max Thrust Force	430kN
Max Pullback Force	860kN
Max Mud Pump Flow	450 L/Min
Max Torque	18500n.M
Diameter of Drill Rod	Ф83
Transport Package	Container
Specification	20GP
Trademark	DILONG
Origin	China
HS Code	84304122
Production Capacity	4 Sets/Month

Product Description

Our company offers variety of products which can meet your multifarious demands. We adhere to the management principles of "quality first, customer first and credit-based" since the establishment of the company and always do our best to satisfy potential needs of our customers. Our company is sincerely willing to cooperate with enterprises from all over the world in order to realize a win-win situation since the trend of economic globalization has developed with anirresistible force.
Our factory is Jiangsu Dilong Heavy Machinery Co.,Ltd,Jiangsu Dilong Heavy Machinery Co.,Ltd is a member of International Society for Trenchless Technology (ISTT) and China Society for Trenchless Technology (CSTT),we started the trenchless industry in 1996, we are the 1st private company who specialized in trenchless technology research and construction in China, at the same time we started the HDD machines manufacture.
We dedicated to export the machines since 2002, until now we have the stable overseas markets in Indian,Vietnam,Thailand,Nigeria,Russia... we got the DL and DM series machines, DL series with traditional gear rack (DL200,DL330,DL430J,DL500L,DL600,DL900,DL1500,DL2800,DL3000,DL4500)and oil cylinder drive directly machines (Patent owned by DILONG),DL450E which is the representative for dual-output cylinder direct drive, DL880 and DL1300 are single-output cylinders; DM series which is modular machine, Oil and electricity combine drive which represent by DM2200, To make machine more stronger, more efficient.We're the guide for Chinese trenchless technology development and improvement.

Q1.What's the difference between "JIANGSU YOUNI" and "JIANGSU DILONG"?
A:Jiangsu Yuni is our global trading company,Jiangsu Dilong is our manufacturing company

Q2. What's your after-sales service?
A:If we already have agent in your local, You'll have the srvice from them.
If not,We'll provide spare parts for free to support you after-sales service , 24-hour online support. Our engineers team will come to site offer guidence if necessary.

Q3. What is your payment terms?
A:Our payment terms is 30% deposit, balance against receiving copy of B/L

Q4.How to be your agent?
A: You have interest in working with us and our products, Focus on our products promotion in your local market,Just contact us, We'll contact you for details.

Q5. How to help me to become your agent?
We'll provide you some free promotional items such as display racks, brochures, T-shirts, hats, notebooks, etc for your potential clients. We'll also help you design products posters to put in the store. You'll have agent price (good price) to occupied the market.

Product Description

Main technical parameters:
Engine	194/2200 KW	Dimension(L*W*H)	7550*2300*2520mm
Max.Thrust force	430/860KN	weight	13T
Max.Pullback force	430/860KN	Diameter of Drill rod	Φ83mm
Max.Torque	18500N.m	Length of Drill rod	3m
Max. Rotary Speed	140rpm	Max diameter of pullback pipe	Φ900mm
Max.Moving speed of power head	50m/min	Max Pullback pipe length	~600m
Mud pump flow	600L/min	incidence angle	1 1~20.
Max.mud pressure	8±0.5Mpa	Climing angle	14
