1000m Deep Hydx
Overview 1.As a traditional geotechnical drilling equipment, crawler drill rig is simple in structure, easy for operatio
Send your inquiryDESCRIPTION
- Overview
- Product Description
- Features
- Product Parameters
- Detailed Photos
- Packaging & Shipping
Basic Info.
| Model NO. | 4 |
| Certification | CE, RoHS, ISO 9001:2000, ISO 9001:2008 |
| Condition | New |
| Drill Hole Diameter | <100mm |
| Drill Hole Depth | >150m |
| Bit Type | Diamond Bit |
| Drilling Way | Compound |
| Type | Crawler |
| Spindle Stroke | 560mm 600mm 600mm 600mm |
| Max. Feeding Force of The Spindle | 45kn 60kn 60kn 90kn |
| The Range of Spindle Rotating Speed | 425-1280 Rpm |
| The Working Pressure | 25MPa |
| Applicable Industries | Hotels, Garment Shops, Building Material Shops, Ma |
| Marketing Type | Hot Product 2023 |
| Transport Package | in Container |
| Specification | 4000*1900*1800mm |
| Origin | China |
| HS Code | 843041290 |
| Production Capacity | 300 Sets Per Year |
Product Description
1.As a traditional geotechnical drilling equipment, crawler drill rig is simple in structure, easy for operation and convenient for maintenance;2.It is a perfect integration of full-hydraulic system with traditional mechanical drill technology;3.Equipped with auxiliary hydraulic hoister and hydraulic mud pump, crawler drill rig has compact structure;4.Due to the rational design, it is convenient for installation and operation;5.Adopting hydraulic lifting drill tower, crawler drill rig is flexible in operation;6.It has perfect stability due to its four hydraulic outriggers;7.Equipped with crawler, crawler drill rig offers easy and flexible movement between worksites.
Product Description
The leading core drill rigs in the developed countries are full hydraulic operated type, which adopt the technology of wire-drawing core with diamond tip. This type of drill rig is also the main developing trend in the field of drill rig technology and related equipment, Under the international and domestic trend, our factory has developed the Full Hydraulic Operated Core Drill Rig. This type of drill rig can take the place of imported products and be applied in the felds of geology, metallurgy, coal mines, petroleum, natural gas and underground water exploration.The rig is track-mounted, which means it can be transported easily. Bottom-contact multi-angle tower, the drilling angle can be adjusted from 45° to 90°, with a low center of gravity and good overall stability.CSXQ600 is equiped with manuel and remote control operation panel, it is simple and accurate.Hydraulic Portable 180m/200m/300m/600m/1000m Core Drilling Rig Machine for Sale is suitable for drilling works such as core drilling, general exploration, geophysical exploration, road and building exploration, blasting hole drilling and so on. With a hole-bottom pressure gauge, easy to control the situation in hole.
Features
Product Parameters
| 1tem | Unit | Parameter | Remark | |
| Drilling Depth | BQ BQ Rod | m | 1000 | Φ55.6mm |
| NQ NQ Rod | 700 | 069.9mm | ||
| HQ HQ Rod | 500 | 88.9mm | ||
| Drill Head Capacity | Rotary Speed | r/min | 0~1145 | 4 gear stepless spee justment |
| MaxTorque | N.m | 4200 | ||
| Hole Diameter of Spindle | mm | 98 | ||
| Max.Liting Capacity | kN | 150 | ||
| Max. Feeding Power | kN | 60 | ||
| Diesel Engine | Rated Power | kW | 132 | 6BTA5.9-C180 |
| Rated Speed | r/min | 2200 | ||
| Mast | Mast Height | m | 9 | |
| Adjusting Angle | * | 0~90 | ||
| Drilling Anglc | * | 45~90 | ||
| Feeding Stroke | mm | 3500 | ||
| Sliding Distance of Mast | mm | 1100 | ||
| Main Hoist | Single-wire Hoisting Capacity | kN | 57 | 1 Layer 1 |
| Dia. of Steel Rope | mm | 16 | ||
| Length ofSteel Rope | m | 50 | ||
| Auxiliary Winch | Single-wire Hoisting Capacity | kN | 12 | 1 Layer 1 |
| Dia of Steel Rope | mm | 6 | ||
| Length ofSteel Rope | m | 1000 | ||
| Mud Pump | Model | 1 | BW-160 | |
| Foot cdlarmp | Clamping Scope | mm | 55,5~117.5 | Φ154 Hole diameter |
| Weight of Main Machine | t | 9.3 | ||
| (××)Overall Dimensions(LxWxH) | mm | 5100×2200×2450 | Transport Dimensions | |
Detailed Photos
Packaging & Shipping
